ss twill wire mesh and 60 mesh 0.27mm and 40 mesh 0.36mm from Anping Zhenghang Metal Products Co.,ltd

Manufacture and supplier of stainless steel wire mesh, stainless steel woven wire mesh ,304 316 316l stainless steel wire mesh,alloy wire mesh and products with high quality and low price. email: ss-wiremesh@outlook.com"
Stainless Steel Wire Mesh Manufacturer and Supplier in China, since 1991- Welcome to Anping Zhenghang Metal products Co.,ltd

Stainless steel wire mesh is also called stainless steel wire cloth,wire netting,steel mesh,stainless steel wire netting,stainless steel wire net, stainless steel square wire mesh, wire mesh screen,stainless steel mesh, stainless steel woven wire mesh ,stainless steel screen and so on .

Stainless steel wire mesh contains chromium and nickel in addition to steel. It is non-magnetic in the annealed condition. After stainless steel wire mesh has been woven, it may become slightly magnetic due to cold working.

The materials usually are:SS304,SS304L,SS316,SS316L,SS321,SS310S,SS430.

The specifications of stainless steel wire mesh is identified by mesh count or opening size./wire diameter.

Stainless Steel Wire Mesh is widely used in mining, construction, paper and many other industries for filtering, sieving and storage. In addition to this, this wire mesh is also applicable as fencing and security solution in gardens, poultry farms and public places. We offer this wire mesh screen in different widths, wire diameters and weaving patterns to meet the requirements of specific industrial applications.

90meshx0.12mm stainless steel wire cloth exported Russia we have a lot stock

stainless steel wire cloth

Material:304&316 stainless steel

Mesh count：90 mesh

Wire Diameter:0.10mm /0.12mm

Width:1m&1.22m&1.3m

Length:100ft

Quantity:200rolls

copper wire mesh 8 mesh countx0.50mm

Copper Mesh

Copper: Copper wire offers excellent electrical and thermal conductivity. It is non-magnetic, anti-sparking and is resistant to atmospheric corrosion, salt air and brine. Copper applications are limited due to its low tensile strength, poor resistance to abrasion and common acids.
Phosphor bronze is an alloy of Tin, phosphorus and Copper. It is corrosion-resisting, wear-resisting, tear-resisting, but not suitable for exposure to hydrochloric acid or strong oxidizing agents.
Weaving methods: Plain weave, twill weave or Dutch weave
Uses: Separation and sifting kinds pellet ,grain, porcelain earth and glass, chinaware printing, filter liquid, etc.
Technical Note:
Standard roll length: 30m，30.5m
Special sizes available at request
Packing: in waterproof paper, PVC bag, wooden pallet. Custom packing available at request.

stainless steel twill weave wire mesh/wire netting 60meshx0.23mm filter discs

Stainless steel wire mesh is also called stainless steel wire cloth,wire netting,steel mesh,stainless steel wire netting,stainless steel wire net, stainless steel square wire mesh, wire mesh screen,stainless steel mesh, stainless steel woven wire mesh ,stainless steel screen and so on .
Stainless steel wire mesh contains chromium and nickel in addition to steel. It is non-magnetic in the annealed condition. After stainless steel wire mesh has been woven, it may become slightly magnetic due to cold working.
The materials usually are:SS304,SS304L,SS316,SS316L,SS321,SS310S,SS430.
The specifications of stainless steel wire mesh is identified by mesh count or opening size./wire diameter.
Twill Weave is a kind of commonly used weaving method.One weft wire passed over two and under two warp wires,and one warp wire passes over and under two weft wires.The wire diamter for both(warp and weft) is mostly the same.It is square aperture. Simply drawing sd beside for your reference.
Stainless Steel Wire Mesh is widely used in mining, construction, paper and many other industries for filtering, sieving and storage. In addition to this, this wire mesh is also applicable as fencing and security solution in gardens, poultry farms and public places. We offer this wire mesh screen in different widths, wire diameters and weaving patterns to meet the requirements of specific industrial applications.
Product Descripsion
stainless steel wire mesh/wire cloth/wire netting/wire net
Mesh count:60meshx60mesh
Wire Diameter:0.23mm
Weave Type:Twill
We have a lot stock all the year

304 &316 Stainless Steel Wire Mesh Cloth for Filtration and Sieve

304 &316 Stainless Steel Wire Mesh Cloth for Filtration and Sieve
Stainless steel is wear-resisting,heat-resisting,acid-resisting and corrosion resisting.Just because of these characteristics,the wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.
Our Stainless Steel Wire Mesh/Wire Netting products are generally made of stainless steel Type 304, Type 304L, Type 316 and Type 316L.We produce wire cloth in all kinds of forms. The weaving is determined according to our customers, specific requirements, such as the material, the wire diameter, the size of the mesh, width and length.

	200 mesh		250 mesh		270 mesh		300 mesh		325 mesh		350 mesh
Diameter	W	S %	W	S %	W	S %	W	S %	W	S %	W	S %
0.060	0.067	27.832
0.055	0.072	32.141
0.050	0.077	36.760	0.052	25.794
0.045	0.082	41.689	0.057	31.035	0.049	27.212
0.040			0.062	36.760	0.054	33.040	0.045	27.832	0.038	23.833
0.035			0.067	42.970	0.059	39.432	0.050	34.412	0.043	30.489	0.038	26.803
0.030			0.072	49.664	0.064	46.390
	400 mesh		450 mesh		500 mesh		550 mesh		600 mesh		635 mesh
Diameter	W	S %	W	S %	W	S %	W	S %	W	S %	W	S %
0.030	0.034	27.832	0.026	21.950
0.025			0.031	31.035	0.026	25.794
0.022							0.024	27.418
0.020									0.022	27.832
0.018											0.022	30.250

W: Mesh Opening, Distance in mm between two adjacent wires.

S%: Working surface. Approximate percentage of the total surface of the openings of the mesh.

Mesh= 25.4/(W+D)

D: Wire diameter (MM)

stainless steel wire cloth/wire netting/wire mesh 50 mesh count 0.18mm

Anping Zhenghang Metal Products Co.,ltd was established in 1991,which is a professional manufacturer of stainless steel wire mesh .It owns corporate strength to qualified and experienced technicians and employees, management and marketing personnel who not only follows worldwide manufacturing standards but also innovates in manufacture, testing, research and development for meeting clients' specific specifications in China and abroad

Stainless steel wire mesh is also named stainless steel mesh,stainless steel screen,stainless steel wire netting and so on.

Plain Weave is a kind of commonly used weaving method.The warp wire that establish the length of the wire mesh and the weft wire,paralled to the width,cross one another.alternating one on the top and one under,forming a 90º angle between each other.Simply drawing as beside for your reference.

Stainless steel is wear-resisting,heat-resisting,acid-resisting and corrosion resisting.Just because of these characteristics,the wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.

Our Stainless Steel Wire Mesh/Wire Netting products are generally made of stainless steel Type 304, Type 304L, Type 316 and Type 316L.We produce wire cloth in all kinds of forms. The weaving is determined according to our customers, specific requirements, such as the material, the wire diameter, the size of the mesh, width and length.

316 stainless steel 24 mesh wire diamter 0.35mm with a lot stock from Zhenghang Factory

Anping Zhenghang Metal Products Co.,ltd was established in 1991,which is a professional manufacturer of stainless steel wire mesh .It owns corporate strength to qualified and experienced technicians and employees, management and marketing personnel who not only follows worldwide manufacturing standards but also innovates in manufacture, testing, research and development for meeting clients' specific specifications in China and abroad.

Mertarial:316 stainless steel
Mesh count:24 mesh
Wire Diameter:0.35mm
Woven Type:Plain
Width:1m-2m
Lenth:100ft

20mesh stainless steel mesh wire diamter0.40mm exported American

Stainless steel wire mesh is also named stainless steel mesh,stainless steel screen,stainless steel wire netting and so on.

Plain Weave is a kind of commonly used weaving method.The warp wire that establish the length of the wire mesh and the weft wire,paralled to the width,cross one another.alternating one on the top and one under,forming a 90º angle between each other.Simply drawing as beside for your reference.

Zhenghang Plain weave stainless steel woven wire mesh/cloth/stainless steel screen offers high filtering efficiency,low pressure loss,constant mesh opening,good dimensional stability,high open surface area and good fireproof property.

Stainless steel is wear-resisting,heat-resisting,acid-resisting and corrosion resisting.Just because of these characteristics,the wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.

Our Stainless Steel Wire Mesh/Wire Netting products are generally made of stainless steel Type 304, Type 304L, Type 316 and Type 316L.We produce wire cloth in all kinds of forms. The weaving is determined according to our customers, specific requirements, such as the material, the wire diameter, the size of the mesh, width and length.

304A Stainless Steel Wire Mesh

Mesh count:20 mesh

Wire Diameter:0.40mm

Width:1m and 1.22m

Length:30m and 100ft

More informations in the below photoes

stainless steel wire mesh canada0.5mesh-2800mesh with competitive price

stainless steel wire mesh canada
As with all of our products, Anping zhenghang takes pride in manufacturing and supplying the highest quality products in the industry and backing that up with the service of our management team, production team and sales group.  As many of you have dealt with our group over the past 15 years I hope that you have found our team to be honest and straight forward in our practices.  We look forward to the additional relationships that will come in the New Year and hope that we may service many of you in the future as we have served so many in the past.  Join the team; join the movement to products Made in the USA, with pride, the good old fashioned way.
Ourfactory perennial with stainless steel screens / stainless steel screen net allthe years.Specifications are as follows:
18mesh x0.17mm/18 mesh x0.18mm/18 mesh x0.19mm/18 mesh x0.23mm/20 mesh x0.15mm/20mesh x0.17mm/20 mesh x0.19mm/24 mesh x0.10mm
Stainlesssteel window screen Width X Length : 50cmx30m/60cmx30m/70cmx30m/80cmx30m/90cmx30m/100cmx30m/110cmx30m/120cmx30m/130cmx30m/150cmx30m
Materials:304 GB stainless steel and 316L stainless steel in TISCO
Ourwire mesh screen has the five advantages:
1,acid and alkali resistance, corrosion resistance, long service time. Lightweight, good toughness, corrosion resistance, good ventilation, Very easilycleanly.
2.anti mouse, strong toughness, high strength can be avoided due to some healthproblems in mice caused by.
3mosquitoes and flies, in the basic use of anti ordinary mosquitoes and insectsbut also can prevent a moist place small wheat midge.
4fire, high temperature resistance, flame retardant, now the buildings have fireprevention facilities, but generally nylon screens can not fire, stainlesssteel screens can meet the basic requirement of fire.
5light, breathable, the surface color is bright and beautiful, compared withordinary nylon screens can better increase the air flow rate and the sun light. Stainlesssteel screens using plain weave weaving technology, has good air permeability,light transmission properties, is a replacement product of our country ordinarynylon screens at present, the product is high grade, wide use, is currently thepreferred high-grade office buildings, doors and windows protection productsfor residential and various buildings and orchard.
How many kinds of woven styles of stainless steel wire mesh? What are these the characteristics ?
Stainless steel mesh is made of stainless steel wire woven, early is the need to use artificial shuttle can be woven, weaving was also relatively simple, a wire on a wire at the bottom of this weave until today, the modern name for plain weave. Different from the traditional one, this time does not require manual participation in new experience today, each production result cannot do without automation, automation equipment, not only saves energy for human time, more important is the diversity of products produced. From a single way to become Plain Weave/ Twill Weave/ Plain dutch weave style/ Twill dutch weave style/.Different weave styles, bring convenience to people's production and life, but also inject new vitality into the society.
Plain Weave style
Plain Weave is a kind of commonly used weaving method.The warp wire that establish the length of the wire mesh and the weft wire,paralled to the width,cross one another.alternating one on the top and one under,forming a 90º angle between each other.Simply drawing as beside for your reference.
Twill weave style
Twill Weave is a kind of commonly used weaving method.One weft wire passed over two and under two warp wires,and one warp wire passes over and under two weft wires.The wire diamter for both(warp and weft) is mostly the same.It is square aperture. Simply drawing sd beside for your reference.
Plain dutch weave style
Woven as a plain weave, but with the warp wires of greater diameter than the weft wires. The weft wires are very close together so that a so-called zero-mesh structure is formed; while the warp wires are thicker and arranged wider apart.
Twill dutch weave style :
Twill dutch weave: "Twill" indicates the warp and weft wires pass alternately above two and below two wires. "Dutch" refers to the use of a heavier warp wire diameter in conjunction with a lighter weft wire diameter. This weave shows a combination of twill and dutch weave.
